Racing Dominance and Early Success
The Ultimate 20 quickly established itself as a formidable force in sportboat racing, earning Sailing World magazine's 1995 Boat of the Year award in the PHRF/Sportboat category. Within its first year of production, approximately 40 boats were ordered for racing in the United States and Europe. The design's performance credentials led to its selection by U.S. Sailing as the official boat for the 1996 Mallory Cup Championships and later for the 2006 Triple Handed Youth Championships.
With a PHRF rating between 138-159 and a sail area to displacement ratio of 36.56, the Ultimate 20 delivered on its promise of multihull-like performance. The boat's ability to plane in moderate breeze while maintaining excellent light-air performance made it competitive across varying wind conditions.
Complex Manufacturing History
The Ultimate 20's production story reflects the challenging economics of specialty sailboat manufacturing. Production began in 1994 with Moore Sailboats in Santa Cruz, California, under Ron Moore's leadership, which completed the first 35 hulls. The design rights and molds subsequently passed through multiple hands due to a series of bankruptcies and disasters.
Ultimate Sailboats, formed in 1993 by Jeff Canepa, had acquired the original Hotfoot 20 molds at a 1988 sheriff's auction and evolved them into the Ultimate 20 design. After Ultimate Sailboats' bankruptcy, production continued through Santa Cruz Yachts (approximately 20 boats), followed by Abbott Boats in Canada until a devastating 2006 plant fire destroyed their facility. Columbia Yachts managed to complete only a few boats before W. D. Schock Corp took over production in the 2010s, though they too eventually ceased Ultimate 20 manufacturing.
Design Innovation and Technical Features
Jim Antrim and Jeff Canepa's design team, which included contributions from Jay Glaser and Larry Tuttle, focused on creating a boat that combined contradictory qualities: the speed of larger racing boats in a trailerable package. The 20.83-foot hull featured several innovative elements including swept spreaders, a retractable bowsprit for asymmetrical spinnaker deployment, and a sophisticated lifting keel system operated by winch.
The construction utilized advanced materials for its era, employing vinylester and polyester fiberglass with balsa core construction. The transom-hung rudder incorporated carbon fiber, while the fractional sloop rig carried 243 square feet of working sail area, complemented by a 452-square-foot spinnaker.
The lifting keel system proved particularly revolutionary, allowing the 450-pound ballast bulb to retract from its racing draft of 5 feet to just 8 inches for trailering. This feature, combined with the boat's rigged weight of 1,260 pounds, meant the Ultimate 20 could be legally towed behind most vehicles without special permits.
Sailing Characteristics and Performance
Pilots consistently praised the Ultimate 20's responsive handling and versatility. The boat's light displacement of 1,100-1,260 pounds and efficient hull shape generated a theoretical hull speed of 5.69 knots, though its planing ability allowed it to exceed displacement speeds in adequate wind. The fractional rig with its 30-foot mast provided excellent balance and control across varying conditions.
The cockpit accommodated racing crews of three to five comfortably, while the interior featured sleeping accommodations for four with a V-berth double forward and convertible settees in the main cabin. A small outboard motor bracket provided auxiliary power for maneuvering in harbors and calm conditions.
Production Legacy and Current Status
Approximately 160 Ultimate 20s were produced across North America during the boat's manufacturing run from 1994 through the 2010s. Despite the cessation of new production, active racing fleets continue to operate in various regions, particularly around Santa Cruz, California, where the design originated.
The Ultimate 20 Class Association now owns the production molds, acquired after the various manufacturer bankruptcies. As Sailing World noted in a 2013 retrospective review, the Ultimate 20 was "cool before sportboats were hip," pioneering the concept of affordable, high-performance trailerable racing that would later influence an entire generation of sportboat designs.
The boat's cultural significance extends beyond its racing achievements. It demonstrated that sophisticated sailing performance need not require a large boat or permanent marina slip, democratizing access to high-level racing and inspiring numerous subsequent trailerable sportboat designs. Today, while no active builders remain, the existing fleet continues to provide competitive one-design racing and serves as testament to innovative design that successfully bridged the gap between dinghy sailing and larger keelboat racing.
