Development and Design
Development of the MAI-223 Kityonok began in 2002 under the direction of project head V. Demin and chief designer V. Lapshin at OSKBES-MAI, the Special Design Bureau of Experimental Aircraft of the Moscow Aviation Institute. The design team announced the project publicly in 2003, having already constructed three prototypes by May of that year. The aircraft made its maiden flight on October 20, 2004, marking the culmination of MAI's decades-long involvement in light aircraft development since the institute's founding in 1930.
The Kityonok was conceived as a versatile STOL ultralight capable of meeting JAR VLA certification standards despite its ultralight classification. Engineers chose a parasol wing configuration to enhance lift characteristics, positioning the 11.40 square meter wing above the fuselage using a DFS airfoil section. The aircraft's innovative construction combined a fiberglass cockpit section with an aluminum frame forward fuselage, while the rear section employed monocoque fiberglass construction.
Technical Innovation
The MAI-223's wing design incorporated significant engineering advances for an ultralight aircraft. The two-spar wing structure utilized aluminum alloy ribs and featured folding capability for ground transport and storage. Control surfaces including ailerons, flaps, and tail components received fabric covering, while the aircraft employed torsion-bar landing gear equipped with hydraulic disc brakes and differential braking capability. Optional landing gear configurations included skis for winter operations and floats for water operations.
Powering the standard configuration is a Rotax 912 ULS engine, an Austrian-manufactured 73.5 kW flat-four powerplant featuring both air and water cooling systems. This engine drives a three-bladed propeller and provides the aircraft with a maximum speed of 110 knots and an optimum cruise speed of 100 knots. Alternative powerplant options included the less powerful Rotax 503UL and 582 UL engines, accommodating different performance requirements and operating costs.
Production and Variants
Production commenced in 2006 with two separate batches of 10 aircraft each initiated by MAI and PRAD respectively. Manufacturing took place at facilities associated with the Moscow Aviation Institute, specifically the experimental production shop EOZ MAI. The Moscow company PRO-Avia handled official supply and distribution arrangements. By 2009, only 4 aircraft had reached completion from the initial 20-unit production run, with total production eventually reaching 6 aircraft.
The first production aircraft was delivered in 2008 to the Tomsk Aero Club, establishing the type's role in Russian general aviation training. A specialized agricultural variant, designated MAI-223SKh, was announced in 2006 and first flew on August 31, 2007. This crop-spraying version incorporated a 160-liter chemical tank and an 8.56-meter spray bar, expanding the aircraft's utility beyond training and recreational flying.
The Manufacturer Legacy
OSKBES-MAI traces its origins to the Moscow Aviation Institute's establishment in 1930, building upon decades of aircraft design experience. The bureau received its design organization certification R-9 on February 17, 1993, subsequently reissued as R-9A on April 20, 1994, and R-52 on April 27, 1998, from the Aviaregister of the Interstate Aviation Committee. Following founder Kazimir Zhidovetskiy's death on June 1, 1999, Nikolay Goryunov assumed the role of Chief Designer.
The company collaborated extensively with Aviatika JSC through a license agreement with MAPO signed on April 10, 1995. OSKBES-MAI transferred exclusive licenses for its Aviatika-series aircraft to MAPO, while continuing development of new designs including the MAI-208 autogyro, which first flew in 2001 and was presented at HeliRussia-2009.
Performance and Specifications
The MAI-223 demonstrates impressive STOL capabilities with a takeoff distance of just 150 meters and landing distance of 100 meters. With an empty weight of 320 kilograms and maximum takeoff weights of 495 kilograms under ultralight regulations or 600 kilograms under JAR VLA standards, the aircraft achieves a range of 400 nautical miles with its 70-liter fuel capacity. Performance includes a service ceiling of 23,000 feet absolute and 21,000 feet optimum, with a climb rate of 1,100 feet per minute.
Modern Development
Technological advancement continued with the MAI-223M variant, which made its first flight on July 1, 2012. This modernized version incorporated tricycle landing gear configuration and an enlarged vertical fin, addressing handling characteristics identified during operational experience with the original taildragger configuration.
Current Status
With only 6 aircraft completed from the original production plans, the MAI-223 Kityonok remains a rare example of post-Soviet Russian ultralight development. The aircraft represents OSKBES-MAI's continued commitment to advancing light aircraft technology, building upon the Moscow Aviation Institute's long tradition of innovative aircraft design that began in the 1930s.
